Ribes sanguineum

Taxonomy: Angiospermae, Saxifragales, Grossulariaceae, Ribes

Links: http://flora.nhm-wien.ac.at/seiten-arten/ribes-sanguineum.htm

Published: 2020-12-15

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): medium-sized (26-50 µm),  size of hydrated pollen (LM): 26-30 µm,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): 26-30 µm,  longest diameter in equatorial or polar view (LM): 26-30 µm,  pollen class: porate,  polarity: -,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): oblique,  P/E-ratio (dry pollen): -,  shape (dry pollen): irregular,  outline in polar view (dry pollen): polygonal,  infoldings (dry pollen): aperture(s) sunken,  aperture number: >6,  aperture type: porus,  aperture condition: porate, pantoporate,  aperture peculiarities: pantoaperturate, annulus

Ornamentation and Structure

LMornamentation LM: psilate,  nexine: -,  sexine: -,  SEMornamentation SEM: psilate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Annotations: pores are irregularly distributed

Author(s) of diagnosis: Halbritter, Heidemarie; Heigl, Helmut

Pictures

hydrated pollen

1. hydrated pollen

hydrated pollen

2. hydrated pollen

hydrated pollen

3. hydrated pollen

hydrated pollen grain

4. hydrated pollen grain

apertures

5. apertures

detail of aperture

6. detail of aperture

dry pollen grains

7. dry pollen grains

Picture legend

  1. hydrated pollen - fresh, glycerine, unstained, photographer: Heigl, H.
  2. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  3. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  4. hydrated pollen grain - fresh, DMP & critical point dried, photographer: Halbritter, H.
  5. apertures - fresh, DMP & critical point dried, photographer: Halbritter, H.
  6. detail of aperture - fresh, DMP & critical point dried, photographer: Halbritter, H.
  7. dry pollen grains - dry, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
