Cornus sanguinea

Taxonomy: Angiospermae, Cornales, Cornaceae, Cornus

Links: http://flora.nhm-wien.ac.at/seiten-arten/cornus-sanguinea-sang.htm

Published: 2020-12-07

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  size of hydrated pollen (LM): 51-100 µm,  shortest polar axis in equatorial view (LM): 51-100 µm,  longest polar axis in equatorial view (LM): 51-100 µm,  shortest diameter in equatorial or polar view (LM): 51-100 µm,  longest diameter in equatorial or polar view (LM): 51-100 µm,  pollen class: colporate,  polarity: isopolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): oblique,  P/E-ratio (dry pollen): prolate,  shape (dry pollen): -,  outline in polar view (dry pollen): triangular,  infoldings (dry pollen): interapertural area sunken,  aperture number: 3,  aperture type: colporus,  aperture condition: colporate, tricolporate,  aperture peculiarities: aperture membrane psilate

Ornamentation and Structure

LMornamentation LM: scabrate, verrucate, gemmate,  nexine: -,  sexine: -,  SEMornamentation SEM: perforate, microechinate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Author(s) of diagnosis: Halbritter, Heidemarie; Heigl, Helmut

Pictures

flower(s)

1. flower(s)

hydrated pollen

2. hydrated pollen

hydrated pollen

3. hydrated pollen

hydrated pollen

4. hydrated pollen

polar view

5. polar view

equatorial view

6. equatorial view

detail of aperture

7. detail of aperture

exine surface

8. exine surface

dry pollen grains

9. dry pollen grains

Picture legend

  1. flower(s), photographer: Halbritter, H.
  2. hydrated pollen - fresh, glycerine, unstained, photographer: Heigl, H.
  3. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  4. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  5. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. detail of aperture - fresh, critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. exine surface - fresh, critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
