PalDat - Palynological Database

an online publication on recent pollen

Epipactis helleborine

Taxonomy: Spermatophyta, Orchidales, Orchidaceae, Epipactis

Published: 2005-06-01

Pollen Description

Shape, Size and Aperture

pollen unit: tetrad,  dispersal unit and peculiarities: tetrad,  size (pollen unit): medium-sized (26-50 µm),  pollen class: -,  polarity: heteropolar,  shape: spheroidal,  outline in polar view: circular,  shape (dry pollen): oblate,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 1,  aperture type: -,  aperture condition: ulcerate,  aperture peculiarities: aperture membrane smooth

Ornamentation and Structure

LMornamentation LM: reticulate,  nexine: -,  sexine: -,  SEMornamentation SEM: reticulate,  TEMtectum: semitectate,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: absent,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: absent

Annotations

The tetrads are not strictly tetrahedric, also planar. The aperture are not exactly at the distal pole.

The tetrads are united to pollinaria which disintegrate.

Author(s) of diagnosis: Halbritter, H.

Pictures

flower(s)

1. flower(s)

hydrated tetrads

2. hydrated tetrads

hydrated tetrad

3. hydrated tetrad

aperture

4. aperture

exine surface

5. exine surface

dry tetrads

6. dry tetrads

Picture legend

  1. flower(s), photographer: Halbritter, H.
  2. hydrated tetrads - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. hydrated tetrad - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. dry tetrads - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

    Copyright and Citation

    Cite this publication as:

    HALBRITTER H., Epipactis helleborine. In: PalDat (2005-06-01) - a palynological database. Published on the Internet https://www.paldat.org/pub/Epipactis_helleborine/101954;jsessionid=8FECC6303994AECCEEB529E99A9F134F [accessed 2018-06-22]
