Fuchsia magellanica

Taxonomy: Angiospermae, Myrtales, Onagraceae, Fuchsia

Published: 2016-12-02

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  pollen class: porate,  polarity: heteropolar,  shape: oblate,  outline in polar view: triangular,  shape (dry pollen): oblate,  outline in polar view (dry pollen): triangular,  infoldings (dry pollen): interapertural area sunken,  aperture number: 3,  aperture type: porus,  aperture condition: porate, triporate,  aperture peculiarities: -

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: microverrucate, perforate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: viscin threads

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Annotations

viscin threads rising from proximal polar area

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

hydrated pollen grains

2. hydrated pollen grains

polar distal view

3. polar distal view

equatorial view

4. equatorial view

aperture

5. aperture

exine surface

6. exine surface

polar proximal area with viscin threads

7. polar proximal area with viscin threads

viscin threads

8. viscin threads

dry pollen grains

9. dry pollen grains

Picture legend

  1. flower(s), photographer: Halbritter, H.
  2. hydrated pollen grains - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. polar distal view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. polar proximal area with viscin threads - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. viscin threads - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
