Glechoma hirsuta

Taxonomy: Angiospermae, Lamiales, Lamiaceae, Glechoma

Published: 2016-11-08

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  size of hydrated pollen (LM): -,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: colpate,  polarity: isopolar,  P/E-ratio: oblate,  shape: -,  outline in polar view: elliptic,  dominant orientation (LM): -,  P/E-ratio (dry pollen): prolate,  shape (dry pollen): -,  outline in polar view (dry pollen): elliptic,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 6,  aperture type: colpus,  aperture condition: colpate, hexacolpate, stephanocolpate,  aperture peculiarities: aperture membrane ornamented, stephanoaperturate

Ornamentation and Structure

LMornamentation LM: reticulate,  nexine: -,  sexine: -,  SEMornamentation SEM: microreticulate,  suprasculpture SEM: -,  TEMtectum: semitectate,  infratectum: columellate,  foot layer: continuous,  endexine: compact-continuous,  intine: monolayered,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: pollenkitt,  reserves in cytoplasm: starch, lipids,  cell number: 3-celled,  Ubisch bodies: absent

Author(s) of diagnosis: Loos, Claudia; Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

polar view,upper focus

2. polar view, upper focus

optical section

3. optical section

polar view,lower focus

4. polar view, lower focus

pollen grain with sperm cells (asterisks)

5. pollen grain with sperm cells (asterisks)

polar view

6. polar view

equatorial view

7. equatorial view

detail of aperture

8. detail of aperture

exine surface

9. exine surface

polar area

10. polar area

dry pollen grains

11. dry pollen grains

dry pollen grain in equatorial view

12. dry pollen grain in equatorial view

pollen grains in cross section

13. pollen grains in cross section

interapertural area of pollen wall

14. interapertural area of pollen wall

aperture

15. aperture

pollen wall at transition of aperture and interapertural area

16. pollen wall at transition of aperture and interapertural area

Picture legend

  1. flower(s), photographer: Loos, C.
  2. polar view, upper focus - fresh, acetolyzed, unstained, photographer: Loos, C.
  3. optical section - fresh, acetolyzed, unstained, photographer: Loos, C.
  4. polar view, lower focus - fresh, acetolyzed, unstained, photographer: Loos, C.
  5. pollen grain with sperm cells (asterisks) - fixed, glutaraldehyde, aceto-carmine, photographer: Loos, C.
  6. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. detail of aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. polar area - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  11. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.
  12. dry pollen grain in equatorial view - dry, sputter coated with gold, photographer: Loos, C.
  13. pollen grains in cross section - fresh, glutaraldehyde & osmium & potassium ferrocyanide, modified Thiéry-test, photographer: Loos, C.
  14. interapertural area of pollen wall - fresh, glutaraldehyde & osmium & potassium ferrocyanide, modified Thiéry-test, photographer: Loos, C.
  15. aperture - fresh, glutaraldehyde & osmium & potassium ferrocyanide, modified Thiéry-test, photographer: Loos, C.
  16. pollen wall at transition of aperture and interapertural area - fresh, glutaraldehyde & osmium & potassium ferrocyanide, modified Thiéry-test, photographer: Loos, C.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
  • Adler W, Oswald K, Fischer R. (1994) Exkursionsflora von Österreich : 1180
