Ipomoea lobata

Taxonomy: Angiospermae, Solanales, Convolvulaceae, Ipomoea

Published: 2020-04-22

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  size of hydrated pollen (LM): -,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: porate, lophate,  polarity: isopolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): -,  P/E-ratio (dry pollen): -,  shape (dry pollen): spheroidal,  outline in polar view (dry pollen): circular,  infoldings (dry pollen): not infolded,  aperture number: >6,  aperture type: porus,  aperture condition: porate, pantoporate,  aperture peculiarities: aperture membrane ornamented, pantoaperturate

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: lophate, echinate, microreticulate, microechinate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: absent

Annotations: dry pollen not or only slightly infolded

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

hydrated pollen

1. hydrated pollen

hydrated pollen

2. hydrated pollen

hydrated pollen

3. hydrated pollen

aperture

4. aperture

exine surface

5. exine surface

exine surface

6. exine surface

exine surface

7. exine surface

dry pollen

8. dry pollen

Picture legend

  1. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  2. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H. 2020. Ipomoea lobata. In: PalDat - A palynological database. https://www.paldat.org/pub/Ipomoea_lobata/303688;jsessionid=1704A02103EA21595EA602BF099B989A; accessed 2020-08-14
