Iris variegata

Taxonomy: Angiospermae, Asparagales, Iridaceae, Iris

Links: http://flora.nhm-wien.ac.at/seiten-arten/iris-variegata.htm

Published: 2020-12-30

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  size of hydrated pollen (LM): 51-100 µm,  shortest polar axis in equatorial view (LM): 51-100 µm,  longest polar axis in equatorial view (LM): 51-100 µm,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: sulcate,  polarity: heteropolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): equatorial,  P/E-ratio (dry pollen): -,  shape (dry pollen): boat-shaped,  outline in polar view (dry pollen): no suitable term,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 1,  aperture type: sulcus,  aperture condition: sulcate,  aperture peculiarities: -

Ornamentation and Structure

LMornamentation LM: reticulate,  nexine: -,  sexine: -,  SEMornamentation SEM: reticulate, free-standing columellae,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Author(s) of diagnosis: Halbritter, Heidemarie; Auer, Waltraud

Pictures

flower(s)

1. flower(s)

flower(s)

2. flower(s)

flower(s)

3. flower(s)

hydrated pollen

4. hydrated pollen

hydrated pollen

5. hydrated pollen

hydrated pollen

6. hydrated pollen

equatorial view

7. equatorial view

sulcus border

8. sulcus border

exine surface

9. exine surface

dry pollen grains

10. dry pollen grains

Picture legend

  1. flower(s), photographer: Svojtka, M.
  2. flower(s), photographer: Svojtka, M.
  3. flower(s), photographer: Svojtka, M.
  4. hydrated pollen - fresh, glycerine, unstained, photographer: Auer, W.
  5. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Auer, W.
  6. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Auer, W.
  7. equatorial view - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. sulcus border - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

    Copyright and Citation

    Cite this publication as:

    Halbritter H., Auer W., Svojtka M. 2020. Iris variegata. In: PalDat - A palynological database. https://www.paldat.org/pub/Iris_variegata/304785;jsessionid=027FCE313B33957567B7568BDD08C280; accessed 2021-06-15
