Kopsia arborea

Taxonomy: Angiospermae, Gentianales, Apocynaceae, Kopsia

Published: 2020-05-15

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  pollen class: colporate,  polarity: isopolar,  shape: spheroidal,  outline in polar view: circular,  shape (dry pollen): isodiametric,  outline in polar view (dry pollen): lobate,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 4,  aperture type: colporus,  aperture condition: colporate, tetracolporate,  aperture peculiarities: -

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: psilate, perforate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Annotations

pollen grains with irregularly arranged additional apertures (colpi)

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

flower(s)

2. flower(s)

polar view

3. polar view

polar view,additional colpus

4. polar view, additional colpus

equatorial view

5. equatorial view

aperture

6. aperture

aperture

7. aperture

exine surface

8. exine surface

dry pollen

9. dry pollen

Picture legend

  1. flower(s), photographer: Weis, B.
  2. flower(s), photographer: Weis, B.
  3. polar view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. polar view, additional colpus - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
