Macleaya cordata

Taxonomy: Angiospermae, Ranunculales, Papaveraceae, Macleaya

Published: 2021-02-09

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): small (10-25 µm),  size of hydrated pollen (LM): 16-20 µm,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): 16-20 µm,  longest diameter in equatorial or polar view (LM): 16-20 µm,  pollen class: porate,  polarity: -,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): oblique,  P/E-ratio (dry pollen): -,  shape (dry pollen): cup-shaped,  outline in polar view (dry pollen): no suitable term,  infoldings (dry pollen): no suitable term,  aperture number: >6,  aperture type: porus,  aperture condition: porate, pantoporate,  aperture peculiarities: pantoaperturate, aperture membrane ornamented

Ornamentation and Structure

LMornamentation LM: scabrate, verrucate, gemmate,  nexine: -,  sexine: -,  SEMornamentation SEM: microreticulate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: absent

Annotations: dry pollen cup-shaped or not infolded

Author(s) of diagnosis: Halbritter, Heidemarie; Heigl, Helmut

Pictures

hydrated pollen

1. hydrated pollen

hydrated pollen

2. hydrated pollen

hydrated pollen

3. hydrated pollen

hydrated pollen

4. hydrated pollen

hydrated pollen

5. hydrated pollen

surface detail

6. surface detail

aperture

7. aperture

aperture

8. aperture

exine surface

9. exine surface

dry pollen

10. dry pollen

Picture legend

  1. hydrated pollen - fresh, glycerine, unstained, photographer: Heigl, H.
  2. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  3. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  4. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. surface detail - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H., Heigl H. 2021. Macleaya cordata. In: PalDat - A palynological database. https://www.paldat.org/pub/Macleaya_cordata/305306;jsessionid=ADF3DB4AF47C720720F301AA40877AC4; accessed 2021-12-05
