Myriophyllum verticillatum

Taxonomy: Angiospermae, Saxifragales, Haloragaceae, Myriophyllum

Published: 2016-12-14

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): medium-sized (26-50 µm),  pollen class: porate,  polarity: isopolar,  shape: oblate,  outline in polar view: circular,  shape (dry pollen): irregular,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): irregularly infolded,  aperture number: 4,  aperture type: porus,  aperture condition: porate, tetraporate,  aperture peculiarities: annulus

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: microgemmate, perforate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations

apertures also elongated resembling short colpi, 3 apertures as well

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

polar view

2. polar view

polar view (3-porate)

3. polar view (3-porate)

equatorial view

4. equatorial view

aperture

5. aperture

exine surface

6. exine surface

dry pollen grains

7. dry pollen grains

Ubisch bodies on inner anther wall

8. Ubisch bodies on inner anther wall

Picture legend

  1. flower(s), photographer: Svojtka, M.
  2. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. polar view (3-porate) - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. dry pollen grains - fresh, sputter coated with gold, photographer: Halbritter, H.
  8. Ubisch bodies on inner anther wall - fresh, rehydrated (water) & sputter coated with gold & critical point dried, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H., Svojtka M. 2016. Myriophyllum verticillatum. In: PalDat - A palynological database. https://www.paldat.org/pub/Myriophyllum_verticillatum/302832;jsessionid=4D4F9B18BBF99D449BF1371F1392C46B; accessed 2018-11-20
