PalDat - Palynological Database

an online publication on recent pollen

Nerium oleander

Taxonomy: Angiospermae, Gentianales, Apocynaceae, Nerium

Published: 2020-12-15

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): medium-sized (26-50 µm),  size of hydrated pollen (LM): 31-35 µm, 36-40 µm,  shortest polar axis in equatorial view (LM): 31-35 µm,  longest polar axis in equatorial view (LM): 36-40 µm,  shortest diameter in equatorial or polar view (LM): 31-35 µm,  longest diameter in equatorial or polar view (LM): 36-40 µm,  pollen class: porate,  polarity: isopolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): oblique,  P/E-ratio (dry pollen): -,  shape (dry pollen): irregular,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): irregularly infolded,  aperture number: 4,  aperture type: porus,  aperture condition: porate, tetraporate,  aperture peculiarities: -

Ornamentation and Structure

LMornamentation LM: psilate,  nexine: -,  sexine: -,  SEMornamentation SEM: psilate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations: 4 or rarely 5 apertures

Author(s) of diagnosis: Halbritter, Heidemarie; Auer, Waltraud

Pictures

flower(s)

1. flower(s)

hydrated pollen

2. hydrated pollen

hydrated pollen

3. hydrated pollen

hydrated pollen

4. hydrated pollen

polar view

5. polar view

slightly oblique equatorial view

6. slightly oblique equatorial view

aperture

7. aperture

exine surface

8. exine surface

dry pollen grains

9. dry pollen grains

Ubisch bodies on inner anther wall

10. Ubisch bodies on inner anther wall

Picture legend

  1. flower(s), photographer: Halbritter, H.
  2. hydrated pollen - fresh, glycerine, unstained, photographer: Auer, W.
  3. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Auer, W.
  4. hydrated pollen - fresh, glycerine, ruthenium red, photographer: Auer, W.
  5. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. slightly oblique equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.
  10. Ubisch bodies on inner anther wall - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
