PalDat - Palynological Database

an online publication on recent pollen

Oenothera macrocarpa

Taxonomy: Angiospermae, Myrtales, Onagraceae, Oenothera

Published: 2016-11-18

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): very large (>100 µm),  size of hydrated pollen (LM): -,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: porate,  polarity: heteropolar,  P/E-ratio: oblate,  shape: -,  outline in polar view: triangular,  dominant orientation (LM): -,  P/E-ratio (dry pollen): oblate,  shape (dry pollen): -,  outline in polar view (dry pollen): triangular,  infoldings (dry pollen): interapertural area sunken,  aperture number: 3,  aperture type: porus,  aperture condition: porate,  aperture peculiarities: aperture membrane ornamented, annulus

Ornamentation and Structure

LM  ornamentation LM: -,  nexine: -,  sexine: -,  SEM  ornamentation SEM: microgemmate, perforate,  suprasculpture SEM: -,  TEM  tectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: viscin threads,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Annotations: viscin threads originating from proximal side

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

flower(s)

2. flower(s)

hydrated pollen grains with viscin threads

3. hydrated pollen grains with viscin threads

polar distal view

4. polar distal view

polar view (oblique)

5. polar view (oblique)

equatorial view

6. equatorial view

aperture

7. aperture

aperture (margin)

8. aperture (margin)

exine surface

9. exine surface

viscin threads

10. viscin threads

viscin thread on pollen surface

11. viscin thread on pollen surface

dry pollen grains

12. dry pollen grains

Picture legend

  1. flower(s), photographer: Buchner, R.
  2. flower(s), photographer: Buchner, R.
  3. hydrated pollen grains with viscin threads - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. polar distal view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. polar view (oblique) - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. aperture (margin) - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. viscin threads - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  11. viscin thread on pollen surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  12. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H., Buchner R. 2016. Oenothera macrocarpa. In: PalDat - A palynological database. https://www.paldat.org/pub/Oenothera_macrocarpa/302326;jsessionid=9114DA9895D2201540E423EB4C388C1D; accessed 2024-04-19
