Ononis cristata

Taxonomy: Angiospermae, Fabales, Fabaceae, Ononis

Published: 2018-10-24

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): medium-sized (26-50 µm),  pollen class: colporate,  polarity: isopolar,  shape: spheroidal,  outline in polar view: circular,  shape (dry pollen): prolate,  outline in polar view (dry pollen): lobate,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 3,  aperture type: colporus,  aperture condition: colporate, tricolporate,  aperture peculiarities: aperture membrane ornamented, margo

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: reticulate, perforate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations

shape in hydrated condition: spheroidal to prolate

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

habitus

1. habitus

oblique polar view

2. oblique polar view

oblique polar view

3. oblique polar view

equatorial view

4. equatorial view

equatorial view

5. equatorial view

equatorial view

6. equatorial view

aperture

7. aperture

aperture

8. aperture

exine surface

9. exine surface

exine surface

10. exine surface

polar area

11. polar area

polar area

12. polar area

dry pollen

13. dry pollen

dry pollen

14. dry pollen

Picture legend

  1. habitus, photographer: Weis, B.
  2. oblique polar view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. oblique polar view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  11. polar area - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  12. polar area - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  13. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.
  14. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H., Weis B. 2018. Ononis cristata. In: PalDat - A palynological database. https://www.paldat.org/pub/Ononis_cristata/303343;jsessionid=9C676AE7B79FE13E66DEF324154D4D77; accessed 2018-11-20
