Ostrya carpinifolia

Taxonomy: Angiospermae, Fagales, Betulaceae, Ostrya

Published: 2016-11-08

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): small (10-25 µm),  pollen class: porate,  polarity: isopolar,  shape: spheroidal,  outline in polar view: circular,  shape (dry pollen): irregular,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): irregularly infolded,  aperture number: 3,  aperture type: porus,  aperture condition: porate, triporate,  aperture peculiarities: aperture membrane ornamented

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: microrugulate, microechinate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: absent,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: -

Annotations

aperture number: 3 to 4

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

polar view

1. polar view

slightly oblique equatorial view

2. slightly oblique equatorial view

aperture

3. aperture

exine surface

4. exine surface

dry pollen grain

5. dry pollen grain

Picture legend

  1. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  2. slightly oblique equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. dry pollen grain - dry, sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H. 2016. Ostrya carpinifolia. In: PalDat - A palynological database. https://www.paldat.org/pub/Ostrya_carpinifolia/302055;jsessionid=20434B7079512ED293C490BD2FC84ECA; accessed 2018-11-14
