Quesnelia marmorata

Taxonomy: Angiospermae, Poales, Bromeliaceae, Quesnelia

Published: 2016-07-06

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): large (51-100 µm),  pollen class: colpate, porate,  polarity: isopolar,  shape: oblate,  outline in polar view: elliptic,  shape (dry pollen): irregular,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): irregularly infolded,  aperture number: 2,  aperture type: porus,  aperture condition: porate, diporate,  aperture peculiarities: aperture membrane smooth

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: reticulate,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations

shape isopolar to slightly heteropolar

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

hydrated pollen

1. hydrated pollen

equatorial view

2. equatorial view

equatorial view

3. equatorial view

oblique view

4. oblique view

aperture

5. aperture

aperture detail

6. aperture detail

exine surface

7. exine surface

exine surface

8. exine surface

dry pollen

9. dry pollen

Ubisch bodies on locule wall

10. Ubisch bodies on locule wall

Picture legend

  1. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  2. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. oblique view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. aperture detail - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.
  10. Ubisch bodies on locule wall - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.

Literature

    Copyright and Citation

    Cite this publication as:

    Halbritter H. 2016. Quesnelia marmorata. In: PalDat - A palynological database. https://www.paldat.org/pub/Quesnelia_marmorata/301185;jsessionid=5BD98533481EB35150487269BDA0F680; accessed 2018-11-15
