PalDat - Palynological Database

an online publication on recent pollen

Ranunculus repens

Taxonomy: Angiospermae, Ranunculales, Ranunculaceae, Ranunculus

Links: http://flora.nhm-wien.ac.at/Seiten-Arten/Ranunculus-repens-1.htm

Published: 2021-06-22

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): medium-sized (26-50 µm),  size of hydrated pollen (LM): 31-35 µm,  shortest polar axis in equatorial view (LM): 31-35 µm,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): 31-35 µm,  longest diameter in equatorial or polar view (LM): 31-35 µm,  pollen class: colpate,  polarity: isopolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): oblique,  P/E-ratio (dry pollen): -,  shape (dry pollen): irregular,  outline in polar view (dry pollen): irregular,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 3,  aperture type: colpus,  aperture condition: colpate, tricolpate,  aperture peculiarities: aperture membrane ornamented

Ornamentation and Structure

LMornamentation LM: verrucate, scabrate, gemmate,  nexine: -,  sexine: -,  SEMornamentation SEM: microechinate, perforate,  suprasculpture SEM: -,  TEMtectum: eutectate,  infratectum: columellate,  foot layer: continuous,  endexine: compact-continuous,  intine: monolayered,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: pollenkitt,  reserves in cytoplasm: starch, lipids,  cell number: 2-celled,  Ubisch bodies: present

Annotations: number of apertures varies

Author(s) of diagnosis: Auer, Angelika; Heigl, Helmut; Auer, Waltraud

Pictures

flower(s)

1. flower(s)

polar view (proximal)

2. polar view (proximal)

optical section

3. optical section

polar view (distal)

4. polar view (distal)

generative cell (asterisk) and vegetetative nucleus

5. generative cell (asterisk) and vegetetative nucleus

hydrated Pollen

6. hydrated Pollen

hydrated Pollen

7. hydrated Pollen

hydrated Pollen

8. hydrated Pollen

polar view

9. polar view

equatorial view

10. equatorial view

exine surface

11. exine surface

detail of colpus membrane

12. detail of colpus membrane

polar view (dry pollen grain)

13. polar view (dry pollen grain)

dry pollen grain in equatorial view

14. dry pollen grain in equatorial view

interapertural area of pollen wall, intine (I), endexine (E)

15. interapertural area of pollen wall, intine (I), endexine (E)

apertural area of pollen wall, intine (I), endexine (E)

16. apertural area of pollen wall, intine (I), endexine (E)

pollen wall (left) and tapetum cells with Ubisch bodies (U)

17. pollen wall (left) and tapetum cells with Ubisch bodies (U)

Picture legend

  1. flower(s), photographer: Auer, A.
  2. polar view (proximal) - fresh, acetolyzed, unstained, photographer: Auer, A.
  3. optical section - fresh, acetolyzed, unstained, photographer: Auer, A.
  4. polar view (distal) - fresh, acetolyzed, unstained, photographer: Auer, A.
  5. generative cell (asterisk) and vegetetative nucleus - fixed, formalin-acetic-alcohol, aceto-carmine, photographer: Auer, A.
  6. hydrated Pollen - fresh, glycerine, unstained, photographer: Heigl, H.
  7. hydrated Pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  8. hydrated Pollen - fresh, glycerine, ruthenium red, photographer: Heigl, H.
  9. polar view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Auer, A.
  10. equatorial view - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Auer, A.
  11. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Auer, A.
  12. detail of colpus membrane - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Auer, A.
  13. polar view (dry pollen grain) - dry, sputter coated with gold, photographer: Auer, A.
  14. dry pollen grain in equatorial view - dry, sputter coated with gold, photographer: Auer, A.
  15. interapertural area of pollen wall, intine (I), endexine (E) - fresh, glutaraldehyde & osmium & potassium ferrocyanide, uranyl acetate & lead citrate, photographer: Auer, A.
  16. apertural area of pollen wall, intine (I), endexine (E) - fresh, glutaraldehyde & osmium & potassium ferrocyanide, uranyl acetate & lead citrate, photographer: Auer, A.
  17. pollen wall (left) and tapetum cells with Ubisch bodies (U) - fresh, glutaraldehyde & osmium & potassium ferrocyanide, uranyl acetate & lead citrate, photographer: Auer, A.

Literature

  • Bergström G, Dobson HEM, Groth I (1995) Spatial fragrance patterns within the flowers of Ranunculus acris (Ranunculaceae). Pl Syst Evol 195: 221-242
  • Fernández I (1985) Morfologia polinica de Ranunculus arvensis L. Anales Asoc Palin Lengua Esp 2: 19-23
  • Oberschneider W (1998) Pollenmorphologie der Ranunculanae. Diplomarbeit. Universität Wien : 125 pp
  • Roland F (1971) Characterization and extraction of the polysaccharides of the intine of the generative cell wall in the pollen grains of some Ranunculaceae. Grana 11: 101-106
  • Turala-Szybowska K (1994) Syncytes in the secretory anthers' tapetum of Ranunculus peltatus (Ranunculaceae). Polish Bot Stud 8: 23-30
  • Adler W, Oswald K, Fischer R. (1994) Exkursionsflora von Österreich : 1180
  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Auer A., Heigl H., Auer W. 2021. Ranunculus repens. In: PalDat - A palynological database. https://www.paldat.org/pub/Ranunculus_repens/306164;jsessionid=C40440726DE36FD965ED50722AAEC941; accessed 2024-03-28
