Spergularia bocconei

Taxonomy: Angiospermae, Caryophyllales, Caryophyllaceae, Spergularia

Published: 2016-01-23

Pollen Description

Shape, Size and Aperture

pollen unit: monad,  dispersal unit and peculiarities: monad,  size (pollen unit): small (10-25 µm),  size of hydrated pollen (LM): -,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: colpate,  polarity: isopolar,  P/E-ratio: -,  shape: spheroidal,  outline in polar view: circular,  dominant orientation (LM): -,  P/E-ratio (dry pollen): prolate,  shape (dry pollen): -,  outline in polar view (dry pollen): lobate,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 3,  aperture type: colpus,  aperture condition: colpate, tricolpate,  aperture peculiarities: aperture membrane ornamented

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: microechinate, perforate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations: apertures also irregular, tricolpate to pantocolpate and spiraperturate

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

hydrated pollen

1. hydrated pollen

polar view

2. polar view

oblique equatorial view

3. oblique equatorial view

hydrated pollen grain

4. hydrated pollen grain

hydrated pollen grain

5. hydrated pollen grain

aperture

6. aperture

aperture

7. aperture

detail of aperture

8. detail of aperture

exine surface

9. exine surface

exine surface

10. exine surface

exine surface

11. exine surface

polar area

12. polar area

dry pollen

13. dry pollen

dry pollen grains

14. dry pollen grains

Ubisch bodies on locule wall

15. Ubisch bodies on locule wall

Ubisch bodies on inner anther wall

16. Ubisch bodies on inner anther wall

Picture legend

  1. hydrated pollen - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  2. polar view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  3. oblique equatorial view - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. hydrated pollen grain - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. hydrated pollen grain - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. aperture - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. aperture - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. detail of aperture - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. exine surface - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  10. exine surface - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  11. exine surface - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  12. polar area - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  13. dry pollen - dry, sputter coated with gold, photographer: Halbritter, H.
  14. dry pollen grains - dry, sputter coated with gold, photographer: Halbritter, H.
  15. Ubisch bodies on locule wall - dry, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  16. Ubisch bodies on inner anther wall - fresh, rehydration (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143
