Victoria regia

Taxonomy: Angiospermae, Nymphaeales, Nymphaeaceae, Victoria

Published: 2016-11-25

Pollen Description

Shape, Size and Aperture

pollen unit: tetrad,  dispersal unit and peculiarities: tetrad tetrahedral,  size (pollen unit): large (51-100 µm),  size of hydrated pollen (LM): -,  shortest polar axis in equatorial view (LM): -,  longest polar axis in equatorial view (LM): -,  shortest diameter in equatorial or polar view (LM): -,  longest diameter in equatorial or polar view (LM): -,  pollen class: tetrad,  polarity: heteropolar,  P/E-ratio: -,  shape: -,  outline in polar view: circular,  dominant orientation (LM): -,  P/E-ratio (dry pollen): -,  shape (dry pollen): -,  outline in polar view (dry pollen): -,  infoldings (dry pollen): aperture(s) sunken,  aperture number: 1,  aperture type: ring-like aperture,  aperture condition: -,  aperture peculiarities: aperture membrane ornamented

Ornamentation and Structure

LMornamentation LM: -,  nexine: -,  sexine: -,  SEMornamentation SEM: psilate, perforate,  suprasculpture SEM: -,  TEMtectum: -,  infratectum: -,  foot layer: -,  endexine: -,  intine: -,  wall peculiarities: -,  supratectal element: -

Miscellaneous

pollen coatings: -,  reserves in cytoplasm: -,  cell number: -,  Ubisch bodies: present

Annotations: aperture may also be interpreted as ulcus with operculum

Author(s) of diagnosis: Halbritter, Heidemarie

Pictures

flower(s)

1. flower(s)

flower(s)

2. flower(s)

hydrated tetrad

3. hydrated tetrad

hydrated tetrad

4. hydrated tetrad

aperture

5. aperture

detail of aperture

6. detail of aperture

exine surface

7. exine surface

polar area

8. polar area

dry tetrads

9. dry tetrads

dry tetrad

10. dry tetrad

Ubisch bodies on inner anther wall

11. Ubisch bodies on inner anther wall

Picture legend

  1. flower(s), photographer: Buchner, R.
  2. flower(s), photographer: Buchner, R.
  3. hydrated tetrad - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  4. hydrated tetrad - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  5. aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  6. detail of aperture - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  7. exine surface - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  8. polar area - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.
  9. dry tetrads - dry, sputter coated with gold, photographer: Halbritter, H.
  10. dry tetrad - dry, sputter coated with gold, photographer: Halbritter, H.
  11. Ubisch bodies on inner anther wall - fresh, rehydrated (water) & critical point dried & sputter coated with gold, photographer: Halbritter, H.

Literature

  • Halbritter, H (1998) Preparing living pollen material for scanning electron microscopy using 2,2-dimethoxypropane (DMP) and criticalpoint drying. Biotechnic Histochem 73: 137–143

Copyright and Citation

Cite this publication as:

Halbritter H., Buchner R. 2016. Victoria regia. In: PalDat - A palynological database. https://www.paldat.org/pub/Victoria_regia/302433;jsessionid=F8006F416D2EF4894A34937B65CA25AC; accessed 2020-12-05
